SPD Surge Protective Device Lightning Protection 1p

Basic Info

Model NO.	ZY2-20
Type	Power Source Arrester
Structure	Zinc Oxide Arrester
Installation	Parallel Arrester
Application	AC/DC System
Size	Small
Operation Voltage	Low Voltage
Material	ZnO
Certification	ROHS, ISO9001, CCC
Brand	Zoll
UC	385V-50/60Hz
in	30ka(8/20us)
Imax	60ka(8/20us)
up	<=2.0kv
Transport Package	Standard Export Packing
Trademark	ZOLL
Origin	China
HS Code	8536300000
Production Capacity	10000PCS/Month

Product Description

General Introduction:Surge protection device(SPD) is an indispensable device for lightning protection of electronic equipment. It is used to limit the instantaneous overvoltage of the power line and signal transmission line to the voltage range that the equipment or system can withstand, or A powerful lightning current drains into the ground to protect the protected equipment or system from impact and damage.Specification:

Model	ZY2-60
Max. Current	60kA
Up	≤2.0kV
Type	T2
Working Voltage	220V/380V
Response Time	≤25ns
Working environment	-40ºC~+80ºC
Structure	Plug-in
Indicator window	Green: normal/Red: fault
Main Application	Protection against indirect lightning and direct lightning effects or other instant overvoltage surges, suitable for surge protection in residential, tertiary and industrial applications

Dimension:

Workshop:
Main Character:1.Metal Oxide Varistor(MOV) Large discharge capacity with low residual voltage and fast response.
2.Welding: Automatic welding to ensure the stability of performance.3.Flame retardant: Flame retardant material. Higher security for users.4.The shell adopts well-recognized PA66 material, high flame retardant,anti-corrosion, harsh environment still normal use.

Application:

With the rapid development of electronic technology, automatic control systems are more and more widely used in all aspects of power production. Whether it is industrial field equipment protection, large-scale system lightning protection, or field instruments, you can get the most from Handele Electric Solutions and professional services. Whether it is the protection of new energy systems such as power grids, rail transit, or coal mines, Handele Electric has long-term vertical industry experience and accumulation, providing customers with industry-focused products and solutions.Power industry: With the rapid development of electronic technology, automatic control systems are increasingly used in all aspects of power production. While power workers benefit from the great convenience of microelectronic technology, they also suffer huge losses once they are damaged. Lightning protection of power system, power plant system, substation, power system, wind power generation, solar photovoltaic power generation.Communication industry: The central office equipment is the transmission node of the entire communication network. After being damaged by lightning, it has a wide range of impact and large losses. Operators' needs for lightning protection are very clear. The Ministry of Industry and Information Technology has also adopted mandatory lightning protection measures for compliance certification of the communication industry.Data center integrated lightning protection, mobile communication equipment room lightning protection, PDU cabinet socket lightning protection, equipment room lightning protection.Construction industry: As the country further advances the Internet of Things, triple play, and smart buildings, each building will become a node in the network. If a core transmission device in the node is damaged, it will affect the entire network .Lightning protection of high-rise buildings, lightning protection of grounding, lightning protection of chimney power supply systemSecurity industry: access control systems, temperature control, light monitoring, security systems, etc. Handa Electric can make building systems smarter, more effective and safer. Kejia products will provide solutions for all types of equipment safety protection in the building.Three-in-one lightning protector, network monitoring system lightning protection, monitoring system lightning arrester system lightning protectionTransportation industry: subway AFC, BAS, PACADA system, etc.; road signal control system, information board system, highway follow-up monitoring system, etc. Safety protection of equipment in the transportation system and safe transmission of information. Kejia can provide a one-stop lightning protection solution.Lightning protection for automobile charging piles, lightning protection for security monitoring system of security bayonet.Petrochemical: Due to the high-risk and explosive characteristics of the petrochemical industry, the demand for lightning protection is also very strong. The demand for lightning protection in the petrochemical industry is mainly in the refining, storage and transportation links.Lightning protection against lightning strikes in oil depots, lightning protection for gas station power supply/systemOther industries: power, communications, construction, security, transportation, petroleum, military industry, factory automation, new energy, all kinds of power supply and signal equipment Handele can provide reliable industry solutions to solve customer worries.

Why Choose Us:

1.Experienced: our team has 13 years of experience2.Factory: Mature technics, strict attitude and perfect quality system3.Before leaving the factory sampling of products for lightning test, strict quality control4.Quality Assurance: Don't let the quality problems do damage to our brand5.Strict quality control, full-inspection. Professionally dedicated to SPD production
